Does anyone have a good clear flat graphic of the back of a Gen6 appliance?
Trying to create some Visio documentation. The Gen6 HW guide has a pretty horrible fuzzy graphic of the back of the appliance. Not really suitable for Visio. Does anyone have a good clear picture or other graphic of this device? Thanks in advance.
ler
No Events found!
echolaughmk
2 Intern
•
522 Posts
0
February 14th, 2017 12:00
RamseyHere
1 Rookie
•
11 Posts
0
February 14th, 2017 12:00
Maybe I should have specified "uncluttered" graphic. Like what you woudl use in a Visio. A 2D flat picture.
ler
RamseyHere
1 Rookie
•
11 Posts
0
February 14th, 2017 13:00
So I have put this togehter from pieces. It's not exactly to scale, but it has all the right stuff. The only thing missing would be a second Fiber card.
Idan
675 Posts
0
February 15th, 2017 06:00
To clarify, the GEN6 RPA has a mandatory 16Gb FC SLIC and another optional 10Gb Copper or Fibre SLIC.
Regards,
Idan Kentor
RecoverPoint Corporate Systems Engineering
@IdanKentor
RamseyHere
1 Rookie
•
11 Posts
0
February 16th, 2017 13:00
So, the four Gen6 appliances that I just installed had only one quad-port fiber card in the left slot and the right slot is empty.
Not sure if it was how they were ordered, but that's what we have.
forshr
2 Intern
•
1.1K Posts
0
February 17th, 2017 13:00
As spec unless an additional 10GbE card was ordered which would fit into slot 1.
