Dell r620 psu
Hi there
I’m new here so i have one question. Can i plug 2 different PSU in to my R620, two PSU it basic same output power (750w) just different model like D750E-S1 and D750E-S3
Thank for your answer
No Events found!
DELL-Young E
Moderator
•
5.1K Posts
0
June 23rd, 2025 07:07
Part #:CWKMX
Part Desc.:PWR SPLY,750W,HVDC,RDNT,DEL,2
For 13G server models
(I don't alternative parts for this)
Part #:5NF18
Part Desc.:ASSY,PWR SPLY,750WP,RDNT,DELTA
For 12G server models
5NF18 can be replaced by 9PXCV, F9F51, 79RDR, W0CTF, N30P9, 6W2PW
To answer your question, these two can't be used together.
Respectfully,
DELL-Young E
Moderator
•
5.1K Posts
0
June 23rd, 2025 03:59
Hello, thanks for choosing Dell.
I'm just wondering where you got this number (D750E-S1 and D750E-S3)
Are there any pictures that you can provide? We will appreciate that.
Respectfully,
Duyduc111
1 Rookie
•
6 Posts
0
June 23rd, 2025 05:23
@DELL-Young E
this is two model i have you see one is d750e s1 and one is d750e s3
DELL-Young E
Moderator
•
5.1K Posts
0
June 23rd, 2025 05:34
Hello could you please try once again? One of the pictures you posted still doesn't show the part that I need to see.
like this.
Would you also kindly send your service tag by DM here? Direct Messaging | DELL Technologies
Respectfully,
Duyduc111
1 Rookie
•
6 Posts
0
June 23rd, 2025 05:41
Sorry for that here is a part number of d750 s3 model :
DP/N OCWKMX
