December 22nd, 2024 03:31
this power connector is different from the 5 pin power switch used in Optiplex 790 or 7010/9020
Responses(3)
December 22nd, 2024 03:35
this is the Optiplex power button cable connector. also5 wires, but its key is mirror image of Inspiron pwr sw connector.
December 25th, 2024 01:14
Dell 500GM has same pin key as the Optiplex power button
December 25th, 2024 01:29
Again the key of pin is different from the white connector for 3668/3650. Dell designed a different color connector as a dummy reminder that it is a different design, even though both have 5 wires that contain pwr sw, pwr led wires
(edited)
